SB822机器人伺服电机修理几种故障没有带负载报过载，怎么处理假如是伺服Run（运转）信号一接入而且没有发脉冲的情况下发作：
查看伺服电机动力电缆配线，查看是否有接触不良或电缆破损；假如是带制动器的伺服电机则必须将制动器翻开；速度回路增益是否设置过大；速度回路的积分时间常数是否设置过小。假如伺服只是在运转过程中发作方位回路增益是否设置过大；定位完成幅值是否设置过小；查看伺服电机轴上没有堵转，并从头调整机械。

6、ABB机器人伺服电机修理几种故障运转时出现反常声音或颤动现象，怎么处理？
伺服配线：
运用规范动力电缆，编码器电缆，操控电缆，电缆有无破损；查看操控线附近是否存在干扰源，是否与附近的大电流动力电缆互相平行或相隔太近；查看接地端子电位是否有发作变化，实在确保接地杰出。

伺服参数：
伺服增益设置太大，主张用手动或主动方法从头调整伺服参数；承认速度反应滤波器时间常数的设置，初始值为0，可测验增大设置值；电子齿轮比设置太大，主张恢复到出厂设置；伺服体系和机械体系的共振，测验调整陷波滤波器频率以及幅值。

机械体系：
衔接电机轴和设备体系的联轴器发作偏移，安装螺钉未拧紧；滑轮或齿轮的咬合不良也会导致负载转矩变化，测验空载运转，假如空载运转时正常则查看机械体系的结合部分是否有反常；承认负载惯量，力矩以及转速是否过大，测验空载运转，假如空载运转正常，则减轻负载或替换更大容量的驱动器和电机。本特利bently3500在钢铁电力化工石化行业的应用和振动监测的测点

　　压缩机归属于通用设备类，较优应用于钢铁、电力、冶金、化工、石化等企业。以下是电机通过齿轮箱拖动压缩机机组使用本特利振动保护系统的配置事例，供大家参考。

　　压缩机组：电机，齿轮箱，压缩机

　　本特利bently3500典型的振动测点布置如下：

　　电机前后轴承箱安装有壳振传感器，用于测量电机轴承的j对振动。齿轮箱的低速端和gao速端分别安装有壳振传感器，用于测量齿轮箱的j对振动。压缩机前后X-Y方向涡流传感器系统，用于监测轴振动。另外，也使用了一套涡流传感器系统测量压缩机轴位移，以及一套涡流传感器系统测量监测键相。振动监测产品系统配置如下：

　　离心式压缩机–蒸汽透平拖动

　　对于工作在危险区域的机组，本特利传感器及监测系统都要带有多机构批准单位选项。而对于工作在安全区的机组，则不做要求。

　　1.测点配置要求

　　键相：压缩机组的每个相同转速的轴系配置一个键相位测点；采用本特利3300XL系列电涡流传感器进行测量。

　　轴振：每个滑动支持轴承上配置一对X/Y方向（互为垂直安装）的轴振测点，采用本特利3300XL系列电涡流传感器进行测量。

　　轴位移：压缩机组的每个推力轴承处配置双冗余的轴向位移测点；采用本特利3300XL系列电涡流传感器进行测量。

　　瓦振（可选）：每个滚动支持轴承上配置两个瓦振测点（水平和垂直方向安装），采用本特利330500系列Velomitor压电式振动速度传感器进行测量。

　　齿轮箱壳振（如适用）：每个齿轮箱的输入和输出轴的支持轴承处各配置一对X/Y方向壳振测点；采用本特利330400系列压电式振动加速度传感器进行测量。

　　超速保护（可选）：每台压缩机组上配置三冗余的超速保护测点，采用3300XL系列电涡流传感器进行测量。2.本特利bently3500配置要求

　　每套关键压缩机组配备本特利3500框架；本特利bently35003500/15电源模块；

　　本特利bently35003500/22M瞬态数据接口模块；本特利bently35003500/25键相模块

　　针对上述轴振、轴位移、瓦振、及壳振测点，本特利bently35003500/42M监测器模块

　　（如适用），超速保护监测测点，需采用3500/53三冗余监测模块，每个监测通道（轴振、轴位移和瓦振）配置d立的两个继电器输出通道；采用本特利bently35003500/32（4通道）或3500/33（16通道）继电器模块，本特利bently35003500/92Modbus通讯网关

　　对于工作在危险区的机组，接入现场信号的3500监测器模块要带有内置安全栅；并且3500框架内要配置3500/04本安接地模块。

　　离心式压缩机–电动机拖动
 ABB motion control has been doing business in China for more than 25 years, so we are very adapted to the speed of China. Our business development has been synchronized with the development of China, and we are committed to shifting our focus from sales and manufacturing to R & D, innovation and digitization. What are the business priorities and development strategies of ABB motion control for the coming 2022? In 2022, abb motion control will always adhere to the customer-oriented principle and continue to vigorously develop major strategic projects. Based on the current fluctuating market situation and the repeated epidemic situation, there are still many uncertainties in the market. In 2022, abb motion control will always adhere to the customer-centric principle and continue to vigorously develop major strategic projects. In the future, we will continue to seize every possible market opportunity, constantly develop new customers and new applications in various industries, strengthen product and technology innovation, improve production efficiency, constantly consolidate the stable recovery trend, continue to implement the concept of energy conservation, efficiency efficiency and low-carbon emission reduction, and promote the transformation of society and intelligent manufacturing. 1. ABB Robot Servo motor repairs several faults and does not work when there is pulse output. How to deal with them?

Monitor the current value of the pulse output of the controller and whether the pulse output lamp flashes, and acknowledge that the command pulse has been fulfilled and the pulse has been output normally; Check whether the control cable, power cable and encoder cable from the controller to the driver are wrongly wired, damaged or in poor contact; Check whether the brake of servo motor with brake has been opened; Monitor whether the panel of the servo driver acknowledges whether the pulse command is input; The run command is normal; The control form must select the azimuth control form; Whether the input pulse type set by the servo driver and the setting of the command pulse are common; Make sure that the driving stop signal of the positive rotation side, the driving stop signal of the rotation side and the reset signal of the error counter are not input, and the load is disconnected and the no-load operation is normal. Check the mechanical system.



2. ABB Robot Servo motor repairs several faults. When the motor error and counter overflow occur during high-speed rotation, how to deal with them?



Motor error counter overflow fault occurs during high-speed rotation.

Countermeasures: check whether the wiring of motor power cable and encoder cable is correct and whether the cable is damaged.



The motor error counter overflow fault occurs when a long command pulse is input.

Countermeasures: if the gain setting is too large, manually adjust the gain from the beginning or use the active gain adjustment function; Extend the acceleration and deceleration time; If the load is too heavy, it is required to select a motor with larger capacity from the beginning or reduce the load, and install a reducer and other drive organizations to improve the load capacity.



Motor error and counter overflow fault occurred during operation.

Countermeasures: increase the overflow level setting value of the error counter; Slow down the rotation speed; Extend the acceleration and deceleration time; If the load is too heavy, it is required to select a motor with larger capacity from the beginning or reduce the load, and install a reducer and other drive organizations to improve the load capacity.



3. ABB Robot Servo Motor repair is not accurate in azimuth control and positioning. How to deal with it?

Firstly, confirm whether the current value of the pulse actually announced by the controller is the same as expected. If not, check and correct the program;

Monitor whether the number of pulse commands received by the servo driver is the same as that announced by the controller; if not, check the control line cable; Check whether the setting of servo command pulse form is the same as that of the controller, such as CW / CCW or pulse + direction;

If the servo gain setting is too large, adjust the servo gain manually or actively from the beginning of the test; When the servo motor is reciprocating, it is easy to generate accumulated errors. It is proposed to set a mechanical origin signal under the conditions allowed by the process, and conduct the origin search operation before the error exceeds the allowed scale; The accuracy of the mechanical system itself is not high or the transmission organization is abnormal (for example, the coupling between the servo motor and the equipment system is offset).



4. ABB Robot Servo Motor repair do azimuth control operation report overspeed fault, how to deal with it?

Once the servo run signal is connected, it will break out: check whether the wiring of servo motor power cable and encoder cable is correct and whether there is damage.

After inputting the pulse command, it occurs during high-speed operation: the pulse frequency output by the controller is too high, and the correction program adjusts the frequency of the pulse output; The electronic gear ratio is set too large; The servo gain setting is too large. Adjust the servo gain manually or actively from the beginning
